MIPI DSI Display Solutions for Embedded Systems

FANNAL provides custom MIPI DSI TFT LCD display solutions with touch integration, optical bonding, and industrial-grade reliability for embedded devices, medical equipment, industrial HMIs, and smart terminals.
Home » MIPI DSI Display

What Is a MIPI DSI Display?

MIPI DSI (Mobile Industry Processor Interface Display Serial Interface) is a high-speed serial interface widely used in embedded systems and smart devices. Compared with traditional display interfaces, MIPI DSI offers lower pin counts, higher bandwidth, reduced power consumption, and more compact hardware designs.

These advantages make MIPI DSI displays a preferred choice for modern embedded applications requiring high-resolution visual performance and efficient system integration.

FANNAL TFT PRODUCT ROADMAP-Version 3.pdf

Product List of Available MIPI DSI Display

Image Product Name Model Size(inch) Resolution Operation Temp(℃) Storage Temp(℃) Display Interface Brightness(cd/m²)
6.86 Inch MIPI Bar Type TFT LCD Display Module with 1000 nits 6.86 Inch MIPI Bar Type TFT LCD Display Module with 1000 nits FN0686D004C 6.86 480×1280 -20~65 -30~80 MIPI 1000
3.4 inch Round TFT LCD Touch Display 3.4" Round TFT LCD Touch Display | 800×800 MIPI IPS FN0340D004A 3.4 800×800 -20~70 -30~80 MIPI 550
9 Inch Capacitive Touch Display 1024×600 MIPI Interface 9 Inch Capacitive Touch Display 1024×600 MIPI Interface FN0900T004B 9 1024*600 -20~70 -30~80 MIPI 510
9 Inch Industrial Touch Display Module | 1024x600 TFT LCD with I2C CTP 9 Inch Industrial Touch Display Module | 1024x600 TFT LCD with I2C CTP FN090AM002 9 1024x600 -20~70 -30~80 MIPI 400
13.4 Inch In-cell TFT Touch Display with MIPI Interface 13.4 Inch In-cell TFT Touch Display with MIPI Interface FN1340T001A 13.4 1200×1920 -20~70 -30~80 MIPI 270
10.1 inch in-cell TFT display 10.1 Inch In-Cell TFT Display for Embedded Systems FN1010D077A 10.1 800*1280 -10~+50 -20~+60 MIPI 400
16 15.6 Inch In-Cell TFT Display | 1200×1920 MIPI | 1000 nits FN1560W001A 15.6 1200×1920 -30-80 -30-80 MIPI 1000
13.4 Inch In-Cell 13.3 Inch In-Cell TFT Display | 1200×1920 MIPI FN1330W001A 13.3 1200×1920 -20~70 -30~80 MIPI 300
8.0 inch in-cell TFT display 8.0 Inch In-Cell TFT Display | 800×1280 MIPI FN0800D028A 8 800*1280 -10~+50 -20~+60 MIPI 300
4.3-Inch In-Cell TFT LCD Module 4.3" In-Cell TFT LCD Display | 480×800 | MIPI Interface FN0430D043A 4.3 480*800 -20~70 -30~80 MIPI 500

Why Choose a MIPI DSI Display?

  • High-Speed Data Transmission
MIPI DSI supports high bandwidth for smooth image transmission and high-resolution displays.

  • Reduced Pin Count
Fewer signal lines simplify PCB routing and reduce connector complexity.

  • Lower Power Consumption
Serial communication architecture helps optimize overall system power efficiency.

  • Compact System Integration
Ideal for space-constrained embedded devices and modern product designs.

Applications of MIPI DSI Display

  • Industrial HMI: Reliable display solutions for industrial control panels and operator interfaces.
  • Medical Devices: Suitable for portable diagnostic equipment and healthcare systems.
  • Handheld Devices: Ideal for scanners, portable terminals, and mobile embedded devices.
  • Smart Home Systems: Supports control panels and intelligent user interfaces.
  • POS Terminals: Provides clear and responsive displays for retail applications.
  • Transportation Equipment: Applicable to vehicle-mounted displays and transportation systems.

Need a Custom MIPI DSI Display Solutions?

MIPI DSI Display Customization

More >>
  • Display sizes from 1.77" to 15.6"
  • IPS, TN, and LTPS panel technologies available
  • Industrial (-20°C to +70°C) and automotive (-30°C to +85°C) temperature options
  • Trusted panel partners including BOE, Innolux, JDI, HannStar, Tianma, and TCL
  • High-brightness solutions available for demanding environments

Interface & Driver Integration

More >>
  • Support for customized MIPI DSI interface configurations based on project requirements
  • Customized FPC design, pin assignments, and cable lengths
  • Interface conversion support: RGB, LVDS, HDMI, SPI, and MCU
  • Driver board solutions available for rapid system integration
  • EMI shielding and signal optimization for reliable performance

Touchscreen Integration

More >>
  • PCAP touch solutions up to 65"
  • G+G and G+F+F touch structures available
  • Multi-touch, glove touch, and waterproof touch support
  • Touch IC options from Microchip, EETI, ILITEK, GOODiX, and FocalTech
  • In-house firmware tuning and EMC optimization

Optical Bonding & Cover Glass

More >>
  • OCA bonding up to 15.6"
  • LOCA/OCR and Silicone bonding up to 32"
  • Custom cover glass with 2.5D/3D designs and silk-screen printing
  • AG, AR, and AF surface treatments available
  • Improved durability, optical performance, and outdoor readability

FAQ About MIPI DSI Display

Related Topics

  • If you’ve ever sourced TFT Displays for an embedded device, you already know the panel itself is only half the story. The interface you choose—LVDS, MIPI DSI, or HDMI—can determine whether your design is stable, easy to integrate, cost-effective, and scalable for future models.
  • Display serial interfaces are not interchangeable technologies competing on performance alone. Each interface—SPI, LVDS, MIPI DSI, and eDP—was designed to solve a specific system-level problem. Understand display serial interfaces, including SPI, LVDS, MIPI DSI, and eDP. Compare bandwidth, cost, distance, and use cases to choose the right interface for industrial and embedded displays.
  • The real decision in parallel vs serial interface is system optimization. Parallel offers simplicity and direct bus-style transfer. Serial offers scalability, cleaner hardware design, and dominance in modern electronics.
    For display and touch products, many industrial systems still use parallel RGB, while newer designs increasingly move toward SPI, LVDS, or MIPI-based serial solutions.
