Touchscreen Details

A complete touch solution integrating Touch Sensor, Touch Controller, and Cover Lens — designed for seamless performance and customization flexibility.

- Competitive cost, color is a little greenish
- Thickness: 1.1mm, 1.8mm, 2.0mm, 3.0mm, 4.0mm

- Scratch resistance and outstanding optical clarity, improved drop performance.
- Thickness: 0.4mm, 0.5mm, 0.55mm, 0.7mm, 1.0mm, 1.1mm, 1.5mm, 2.0mm

- CNC process: making a certain cutting for different thickness branding PMMA, such as Mitsubishi
-Injection molding process: directly injection molding through different shapes of models
- Thickness: 0.5mm, 0.8mm, 1.0mm, 1.2mm, 1.5mm, 2.0mm, 3.0mm

IK code and impact energy (values changed in Amd 1:1998)
IK code	IK00	IK01	IK02	IK03	IK04	IK05	IK06	IK07	IK08	IK09	IK10
Impact energy (joules)	*	0.15	0.2	0.35	0.5	0.7	1	2	5	10	20

By chemical etching or spraying, the reflective surface of the original glass is changed to a diffused surface, which changes the roughness of the surface of the glass, thereby producing a matte effect on the surface. When the outside light is reflected, it will form a diffuse reflection, which will reduce the reflection of light and achieve the purpose of not glare so that the viewer can experience better sensory vision. It can be used for transportation, ATM, POS, Medical, Ticket Machines, Vending Machines, and so on.

 Gloss: 30~110
 Haze: 0.04~0.17
 Roughness: 3~40
 Transmissivity: >89%

AR(Anti-Reflection) is a coating on the glass surface that reduces reflectivity and increases transmittance. By increasing the transmittance of the glass, the content of the display is more clearly presented, allowing the viewer to enjoy a more comfortable and clear sensory vision.

 Singer or double-side AR according to customer’s needs
 Transitivity: ≥ 95% in the range of 450~650nm, ≥ 96% at 550nm
 Reflectivity: ≤ 1.5% in the range of 450~650nm, ≤ 1% at 550nm
 Reflection Color: between blue-violet and red-violet

AF(Anti-Fingerprint), also known as easy-to-clean coatings, is a coating on the glass surface composed of a layer of nano-chemical material. It helps to control water drop angle and increases abrasion resistance. You can easily wipe off dirt, dust, fingerprints, oil stains, etc. The surface is smoother and feels more comfortable.

 Water & other liquids resistance by increasing water contact angle with the glass surface
 Helps to increase abrasion resistance
 Easier to wipe off dirt, dust, fingerprints, oil stains
 The surface is smoother and feels more comfortable to touch.
 Higher scratch resistance

AB(Anti-Bacteria) is to impart antimicrobial properties with greater than 99 percent bacterial reduction. Fannal’s approach is called ion exchange, through a special technique, AG/CU dual-ions are implanted into the glass surface, both of which excel in sterilization. Silver ions can destroy more than 650 pathogens. At the same time, thanks to its strong reducibility, it can repeatedly carry out the anti-bacterial process. Silver ions achieve a bacteriostatic effect through metal ionization and photocatalysis.

 Antibacterial CG and touchscreen solutions
 Antibacterial glass has a very good antibacterial effect
 Also, excellent optical properties and surface scratch performance
 Suitable solutions and professional services, especially medical, public transportation, and industrial HMI applications
