7-Inch curved cover and TFT design with advanced features

7 inch 1024×600 curved cover TFT display module

Name: 7 inch 1024×600 curved cover TFT display module
Brand: FANNAL
Rating: 5.0 (60 reviews)

7 inch Curved Cover IPS TFT LCD Display Module – 1024×600 Industrial Panel

Model:
FN0700191001A
Brand:
FANNAL
Size(inch):
7
Cover OD (mm):
153.2(H)x84.9(V)
Operation Temp(℃):
-30-80
Storage Temp(℃):
-30-85
Style:
High Brightness Display
Resolution:
1024×600
Display Interface:
RGB 24bit
Brightness(cd/m²):
1200

Quantity:
Availability:





Inquiry Add to Basket

7 inch curved cover IPS TFT LCD curved cover TFT LCD curved cover TFT display curved cover LCD

Product Features

Product Drawing

Specification

Product Application

Add Ons

The 7-inch Curved COVER+ LCM module is a cutting-edge display solution designed to meet the demands of modern applications requiring high performance, durability, and aesthetic appeal. This display module combines a sleek curved TFT design with advanced features, making it ideal for a wide range of industries and use cases.

Key Features

Display Specifications

Screen Size: 7.0 inches (Diagonal)
Resolution: 1024(H) × 600(V)
Pixel Pitch: 0.1506(H) × 0.1432(V)
Active Area: 154.2(H) × 85.9(V)
View Area: 153.2(H) × 84.9(V)

Design & Build

Curved Cover Glass: Enhances aesthetics and usability.
Module Size: 183.9(W) × 131.0(H) × 7.58(D), compact and versatile for integration.
Display Mode: Normally Black, ensuring high contrast and vibrant colors.

Performance

Viewing Direction: ALL, offering a wide viewing angle for excellent visibility from any position.
Interface: RGB 24-bit, providing seamless integration and high-speed data transmission.
Operating Temperature: -30°C to 80°C, designed for extreme environments.
Storage Temperature: -30°C to 85°C, ensuring durability and reliability across a wide temperature range.

Why Choose the 7-Inch Curved COVER+ LCM Module?
This module combines premium aesthetics with robust performance, making it a top choice for industries requiring reliable and visually appealing display solutions. Its wide viewing angle, high resolution, and ability to perform in extreme conditions ensure that it meets the demands of both high-end and rugged applications.

Product Drawing

FN0700T191A drawing

Specification

Size(inch):	7.0
Module:	FN0700191001A

TFT LCD
Resolution:	1024x600
Brightness（cd/m²）:	1200
Display interface:	RGB 24bit
Panel type:	IPS

Cover
Cover type:	curved cover
Cover printing:	Anti-UV coating

Applications

This 7-inch curved cover display module is ideal for a variety of industrial and commercial display applications:

Automotive Displays: Ideal for dashboards, infotainment systems, and rear-seat entertainment.
Smart Home Devices: Perfect for control panels, smart mirrors, and interactive home displays.
Industrial Equipment: Suitable for HMI (Human-Machine Interface) displays in manufacturing and automation.
Medical Devices: Enhanced clarity and durability for diagnostic equipment and monitoring systems.

Automotive Display

Embedded touchscreen

Smart Home Display

industrial-panels

Industrial Display

medical display

Medical display

Customization

Touch Panel: Featuring a custom cover lens and touch sensor, with expertly selected touch ICs. Configurations available in both COF (Chip on Flex) and COB (Chip on Board) for tailored solutions.

Bonding: Options include both air bonding and optical bonding, with professional selection managed by FANNAL to ensure optimal performance and clarity.

TFT Display: Developed in-house, this TFT display is sunlight-readable, operates across a broad temperature range, and incorporates IPS technology for superior viewing angles and color accuracy.

Add-ons: Available with a range of additional accessories to expand functionality.

FAQ

Q1: Can this display be used with standard RGB-based controllers?

A:
Yes. It uses a 24-bit RGB interface that integrates with most industrial controllers and microcontrollers that support RGB TTL signals — ideal for embedded platforms, FPGA boards, and custom systems.

Q2: What should I check before integrating this display into my system?

A:
Before integration, confirm:
– Your controller supports RGB 24-bit output
– Module power requirements match your supply
– The operating temperature range fits your environment
We can also provide pin-outs and timing documents upon inquiry.

Q3: Is this display suitable for harsh environments?

A:
Yes. With a -30°C to +80°C operating range and robust high-brightness panel, this module is built for industrial and ruggedized applications.

Q4: Does this module include touch functionality?

A:
This specific SKU is a display-only module with curved cover glass — touch functionality is not included. If you require touch integration, we can offer a separate touch version or custom solution.

Q5: What customization options are available?

A:
For volume orders, we can support:
– Optical treatments like anti-glare/anti-UV
– Cover printing or special coatings
– Pin layout adjustments and interface tailoring
Contact our team for design requirements and lead-time details.
