7.0-inch Industrial Wide Temperature AMOLED Display

7.0 Inch Wide Temperature AMOLED Display | -30°C to +85°C Industrial Panel

Model:
FN0700E127A
Size(inch):
7
Operation Temp(℃):
-30~+85℃
Storage Temp(℃):
-40~+85℃
Resolution:
1080×1920
Direction:
ALL
Interface:
MIPI
Brightness(cd/m²):
600
Touch Screen:
Can be chosen

Quantity:
Availability:





Inquiry Add to Basket

7.0-inch AMOLED Display Wide Temperature AMOLED Display Industrial AMOLED Display

Key Features

Product Drawing

Specification

Product Application

About FANNAL

7.0-inch AMOLED display, 1080×1920, MIPI, 600cd/m²

This AMOLED display, featuring a 7.0-inch screen with a resolution of 1080×1920, offers a high brightness of 600cd/m² and utilizes the MIPI interface. Its elongated form factor and advanced technology make it suitable for various applications, including wearable devices, portable gaming consoles, medical instruments, and automotive displays.

Key Features

Wide Operating Temperature Range
Designed to operate reliably from -30°C to +85°C, suitable for industrial and outdoor environments with extreme temperature variation.
AMOLED Self-Emissive Technology
Provides high contrast, deep blacks, and fast response without backlight dependency, maintaining visual stability across temperature ranges.
7.0-Inch Compact Form Factor
Ideal size for embedded systems, portable industrial devices, and space-constrained equipment.
Stable Performance in Low-Temperature Conditions
AMOLED panel and driver design optimized for cold-start and low-temperature operation compared with conventional LCD solutions.
Industrial-Grade Reliability
Engineered for continuous operation in harsh environments where standard commercial displays may fail.

This 7.0-inch AMOLED display is a powerful solution for applications demanding high-definition visuals and responsive touch capability, providing an optimal balance of performance, energy efficiency, and visual quality for modern devices.

Drawing

屏幕截图 2024-10-24 110031

Specifications

General Specifications：

LCD size(inch):	7.0 (Diagonal)
Resolution:	1080(H)×1920(V)
Pixel Pitch:	80.5(H)x80.5(V)
Active Area(mm):	86.94(H)×154.56(V)
Module Size(mm):	89.04×161.11×0.822
Display type:	AMOLED
Interface:	MIPI
View Direction:	ALL
Power Supply:	3.3
Luminance(cd/m2):	600(Typ.)

Interface:

Pin No.	Symbol	I/O	Description
1	NTP_PWR	P	OTP Panel.
2	VCI	P	Supply analog voltage.
3	AVDD_EN	I	AVDD enable signal.
4	SWIRE	O	Swire protocol setting pin of Power IC.
5	TE	O	Synchronous signal output from panel to avoid tearing effect.
6	RESET	I	Reset signal input.
7	GND	P	Ground.
8	D2N	I	MIPI DSI Negative differential data signal.
9	D2P	I	MIPI DSI Positive differential data signal.
10	GND	P	Ground.
11	GND	P	Ground.
12	D1N	I	MIPI DSI Negative differential data signal.
13	D1P	I	MIPI DSI Positive differential data signal.
14	GND	P	Ground.
15	GND	P	Ground.
16	CLKN	I	MIPI DSI Negative differential data signal.
17	CLKP	I	MIPI DSI Positive differential data signal.
18	GND	P	Ground.
19	GND	P	Ground.
20	D0N	I	MIPI DSI Negative differential data signal.
21	D0P	I	MIPI DSI Positive differential data signal.
22	GND	P	Ground.
23	GND	P	Ground.
24	D3N	I	MIPI DSI Negative differential data signal.
25	D3P	I	MIPI DSI Positive differential data signal.
26	GND	P	Ground.
27	GND	P	Ground.
28	VDDI	P	Power supply for display driver IC interface and logic system.
29	VDDI	P	Power supply for display driver IC interface and logic system.
30	GND	P	GROUND.
31	GND	P	GROUND.
38-41	ELVDD	P	Power supply for panel.
42	AVDD	P	Signal analog voltage.
43	AVDD	P	Signal analog voltage.
44	GND	P	GROUND.
45	GND	P	GROUND.
46	TP_AVDD	P	Power supply.
47	TP_SCL	I/O	I2C clock signal.
48	TP_INT	O	Interrupt signal, asserted to request Host start a new transcation
49	TP_SDA	I/O	I2C data signal.
50	TP_1.8V	P	Power supply.
51	TP_RST	I	External reset signal.

Applications

Automotive Systems
Suitable for use in automotive dashboards or infotainment systems, the display’s clarity and rich color reproduction ensure a user-friendly interface for navigation, multimedia, and vehicle information.
Portable Electronics
Ideal for portable devices such as handheld gaming consoles or e-readers, this display’s high resolution and energy efficiency offer long-lasting performance while maintaining vibrant image quality.
Smart Home Devices
The display can be integrated into smart home control panels, offering a clear and intuitive interface for managing home automation systems, from lighting to security.
Outdoor Industrial Equipment
Devices are exposed to seasonal temperature changes, including cold starts and high-temperature operation.
Medical & Diagnostic Devices
Equipment requiring consistent display performance across a wide environmental range.

About FANNAL

FANNAL, founded in 2011, is a specialist in touch display solutions, delivering high-quality products and technical services worldwide. We design and manufacture in-house custom Displays, PCAP touch screens, and optical bonding. Our solutions serve industrial, outdoor, medical, automotive and other applications.

We are a fast-growing high-tech company financially backed by SECO, a European leader in electronic devices and embedded computing. We hold ISO 9001, ISO 14001, ISO 45001, ISO 13485, and IATF 16949 certifications. Our products are REACH and RoHS compliant, with test reports or declarations available upon request.

With stable quality and engineering support, FANNAL helps customers stay competitive and differentiate their products globally.

Well-Experienced: 15 years of experience in TFT Displays, AMOLED Displays, Touch Displays, Capacitive Tuchscreens, and Touch Monitors manufacturing.

One-Stop Solution: Full in-house process for touch screen, display, and optical bonding

Global Service: Italy, Germany, France, Spain, India, Japan, Singapore, and more — timely local support.

Strong Background: Financially backed by SECO, a top European leader in embedded and display solutions.

Reliable Supply: Our long-term supplier network ensures you receive consistent quality and reliable delivery, even in high-demand seasons.

Quality Assurance: ISO 9001, ISO 14001, ISO 45001, ISO 13485 & IATF 16949 certified; REACH & RoHS compliant.

Quality Control

quality certificate

Quality Inspection

FAQ

Q1: What does “wide temperature AMOLED display” mean in practice?

A:
It refers to a display designed to operate reliably beyond standard industrial limits. With a -30°C to +85°C operating range, this AMOLED display supports cold starts and stable performance in environments where typical displays may show slow response, image retention, or failure.

Q2: Is -30°C necessary for my application?

A:
If your device is used outdoors, in unheated enclosures, or in regions with cold winters, displays rated only to -20°C may suffer from delayed startup or image instability. A -30°C rating provides additional design margin and long-term reliability.

Q3: Does AMOLED perform better than LCD in wide temperature environments?

A:
AMOLED displays do not rely on liquid crystal behavior or backlight modules, which can be affected by low temperatures. This makes AMOLED more stable in cold environments when properly designed.

Q4: Is this display automotive-grade?

A:
No. While it supports a wide temperature range, this display is designed for industrial applications and is not certified to automotive standards such as AEC-Q.
