23.6-inch 1920*1080 LCD Screen Curved Monitor (C-shaped with Lighting)

23.6″ Curved Touch Screen Monitor 1920×1080 for Gaming

Name: 23.6″ Curved Touch Screen Monitor 1920×1080 for Gaming
Brand: FANNAL
Rating: 5.0 (92 reviews)

23.6-inch touch screen curved monitor

Model:
FN236CVM
Brand:
FANNAL
Size(inch):
23.6
Display AA(mm):
293.3*517.01
Operation Temp(℃):
/
Storage Temp(℃):
/
Contrast Ratio:
3000:1
Monitor Size:
598.63*365.78*89.91
Style:
Black (White optional)
Resolution:
1920×1080
Direction:
89/89/89/89 (CR≥10)
TP Interface:
USB
Brightness(cd/m²):
250

Quantity:
Availability:





Inquiry Add to Basket

Curved Monitor gaming monitor

Brief Introduction

Drawing & Specifications

Product Application

Customization

FAQ

Brief Introduction

Core Specifications

Immersive Display: 23.6-inch R1500 curved screen for a wrap-around field of view and enhanced depth.
Visual Excellence: FHD (1920x1080) resolution paired with a 3000:1 high contrast ratio for deep blacks and vibrant colors.
Responsive Touch: Advanced capacitive multi-touch technology ensures fluid, intuitive interaction.

Key Advantages

Built for Performance: Engineered for durability in high-traffic or heavy-usage environments.
Versatile Setup: VESA mount compatibility offers flexible installation for any workspace or gaming rig.
Ergonomic Design: The R1500 curvature reduces eye strain while maximizing immersion.

Drawing

屏幕截图 2024-10-18 151619

Specifications

Size(inch):	23.6
Module:	FN2306CVM
TFT LCD
Resolution:	1920×1080
Brightness（cd/m²）:	250
Physical shape:	Curved Screen, R1500
Touch panel
Touch type:	capacitive touch
TP Interface:	USB
Number of Touch:	10
Tractor parameter
Product size(mm):	598.63x365.78x89.91
Power input:	DC 12V 4A
Support system:	Windows7; Android 4.4; Linux 4.4
I/O joggle:	HDMI、VGA、USB

Application

Interactive Gaming Stations — Ideal for PC and console gaming with curved immersive view.
Interactive Kiosks & Signage — Touch capabilities make this suitable for public info displays.
Multimedia Terminals — Used in entertainment, education, and corporate AV setups.
Digital Retail Displays — Curved high‑contrast visuals attract attention in POS and digital signage.
Control & Monitoring Panels — Interface displays in industrial and commercial systems where touch interaction is needed.

curved monitor application1x

Customization

Cover Lens Specifications:

Shape: Custom-designed into specific shapes to meet requirements.
Printing: Available options include silk printing and ceramic printing.
Material: Offered in either PMMA or glass.
Thickness: Varies from 0.55 mm to 10.0 mm.
Surface Treatment: Treatment options feature anti-glare (AG), anti-reflective (AR), anti-fingerprint (AF), and anti-bubble (AB).

Sensor Features:

Manufacturer: Sensors are produced by FANNAL.
Design: Incorporates a narrow bezel for a sleek appearance.
Thickness: Various thickness options are available.

Flexible Printed Circuit (FPC) Characteristics:

Shape: Custom shapes can be created to fit specific applications.
Touch IC: A variety of touch IC options are available for selection.
Interface: Multiple interface choices provide flexibility in design.

Bonding Techniques:

Methods: Available bonding methods include air bonding and optical bonding.
Performance: Designed to minimize reflection and achieve an all-black effect.

TFT Display Attributes:

Manufacturing: Capable of in-house manufacturing.
Visibility: Features a sunlight-readable display that operates well across a wide temperature range.
Technology: Utilizes IPS TFT technology for superior viewing angles.
Grade: Automotive-grade display ensures long-lasting durability.

Add-On Options:

Customization: Offers various add-ons, including backlight boards, AD boards, and wire sets to enhance functionality.

FAQ

Q1: What are the mechanical and visual advantages of a curved touchscreen monitor in gaming and interactive terminal design?

A1: The ergonomic curvature profile aligns perfectly with the human eye's natural field of view, drastically reducing peripheral visual distortion. For gaming hardware and immersive kiosks, it provides uniform viewing distances to all screen coordinates, enhancing user focus and mitigating external glare reflections.

Q2: Why is the 3000:1 static contrast ratio critical for digital entertainment and high-end slot machines?

A2: Unlike standard IPS displays capped at 1000:1, this display utilizes high-contrast vertical alignment principles. A 3000:1 static contrast ratio yields exceptionally deep true black levels and vivid color rendering, ensuring critical details inside dark graphics layers don't appear washed-out or muddy under bright casino or retail ambient lights.

Q3: Can Fannal customize the outer chassis style, colors, and mechanical mounting configurations for this 23.6" monitor?

A3: Yes, while black is standard and white is optional, Fannal provides flexible industrial design customization. We can engineer bespoke open-frame brackets, custom front bezels, integrated flush VESA mounts, or custom silk-screened branding logos according to your cabinet integration parameters.

Q4: How does the integrated PCAP touch controller handle rapid input demands typical in interactive gaming scenarios?

A4: The integrated high-performance touch IC protocol supports multi-touch interactions over a standard USB HID interface, ensuring sub-10ms response times. The firmware can be custom-tuned by our engineers to support thick protective cover glass scaling or gesture tracking without experiencing latency or false coordinate offsets.

Q5: What optical surface treatments are recommended if this 23.6-inch monitor is integrated into a high-traffic public space?

A5: For high-traffic commercial terminals, we highly recommend custom cover glass processing with Anti-Fingerprint (AF) oleophobic layers to minimize grease smudges and Anti-Glare (AG) chemical etching to suppress harsh ceiling reflection noise, ensuring continuous legibility and ease of maintenance.
