13.3 inch TFT display 1920x1080 resolution with capacitive touch screen

Name: 13.3 inch TFT display 1920x1080 resolution with capacitive touch screen
Brand: FANNAL
Rating: 5.0 (97 reviews)

13.3-inch touch display module | Embedded Display for Smart Home

Model:
FN133TPM
Brand:
FANNAL
Size(inch):
13.3
Cover OD (mm):
314.21x262.41x4.9
Display AA(mm):
293.47*165.08
Operation Temp(℃):
-20~70
Storage Temp(℃):
-20~70
TP VA (mm):
292.47x164.08
Resolution:
1920x1080
Display Interface:
LVDS
TP Interface:
USB
Brightness(cd/m²):
400

Quantity:
Availability:





Inquiry Add to Basket

vending machine touch screen china touch screen suppliers custom touch screen

Product Features

Drawing & Specifications

Add Ons

Product Application

FAQ

Introducing a 13.3-inch TFT display with a resolution of 1920x1080, designed for high-quality visuals and interactive experiences. This display features a capacitive touchscreen for responsive and accurate touch interactions. It incorporates a microchip driver IC, ensuring reliable performance and compatibility. The touch interface connects via USB, while the display interface utilizes LVDS for high-speed data transfer. Additionally, the surface treatment is anti-glare (AG), reducing reflections and enhancing visibility in various lighting conditions. Ideal for a range of applications, this display combines functionality with a sleek design.

Features – 13.3" TFT 1920×1080 Capacitive Touch Display

Screen Size & Resolution – 13.3-inch Full HD (1920×1080) TFT panel. Ideal for embedded and smart home interfaces.
Touch Technology – Projected capacitive (PCAP) multi-touch, precise and responsive for control panels or interactive devices.
Panel Type – IPS for wide viewing angles and consistent color reproduction.
Anti-Glare & Optical Quality – Anti-glare coating reduces reflections, ensures clear outdoor and indoor visibility.
Interfaces – LVDS and USB for easy integration with embedded boards or smart home controllers.
Operating Range – Wide temperature support: -20°C to 70°C for industrial and home environments.
Durability & Reliability – Long lifespan, stable performance in continuous operation for embedded applications.

Drawing

屏幕截图 2024-10-28 175721

Specifications

Size(inch):	13.3
Module:	FN133TPM

TFT LCD
Resolution:	1920x1080
Brightness（cd/m²）:	400
Display interface:	LVDS
Panel type:	IPS

Touch panel
Touch type:	Capacitive touch
TP VA (mm):	292.47x164.08
Cover OD (mm):	341.21*262.41x4.9
TP Interface:	USB
Diver IC:	Microchip

Customization

COVER LENS:

Shape: cut in special shape, Printing: Silk printing/Ceramic printing, Material: PMMA/Glass, Thickness: 0.55mm~10.0mm, Surface treatment: AG, AR, AF, AB.

Sensor:

Sensor made by FANNAL,Narrow bezel design,Thickness selectable.

FPC:

Required shape available, Touch IC selectable, Interface selectable.

Bonding:

Air bonding/optical bonding, low reflection, All one black effect.

TFT Display:

In house manufacture/sunlight readable display/wide temperature display, IPS TFT display, Automotive grade display.

Add-on:

backlight board, AD board, wire sets.

Application

With the demand for custom projects going up every day, the bar type TFT market is growing correspondingly. And our bar type TFT solution can be perfectly used in many applications like industrial, automotive, medical, home appliance and maritime, etc.

Smart Home Control Panels – Touch interfaces for lighting, HVAC, security, and entertainment systems.
Embedded Devices – Suitable for industrial controllers, IoT terminals, and interactive kiosks.
Medical & Health Devices – Compact and reliable touch interface for patient monitoring or device control.
Commercial Displays – Smart vending machines, POS terminals, or information kiosks requiring responsive touch and clear visuals.
Prototyping & Development – Engineers can integrate with microcontrollers, SBCs, or custom embedded boards.

Automotive

Payment Systems

Transportation

E-bike

Outdoor

Industrial Panels

Medical Equipment

Fintness Equipment

Engineering Plant

Motorbike

Vending Machine

Home Application

FAQ

Q1: Does the USB interface of this 13.3" capacitive touch screen support plug-and-play across different Operating Systems?

A1: Yes, the integrated PCAP controller supports standard USB HID protocols, ensuring native plug-and-play compatibility with Windows, Linux, and Android systems without the need for installing external manual drivers.

Q2: What type of bonding technology is used between the 13.3-inch TFT LCD panel and the capacitive touch sensor?

A2: We offer both air bonding (tape bonding) and advanced optical bonding (OCR/OCA) options for this module. For industrial and medical hardware demanding high impact resistance and superior optical clarity, optical bonding is highly recommended.

Q3: Can the 4.9mm cover glass be customized for special thickness, anti-glare (AG), or anti-fingerprint (AF) treatments?

A3: Absolutely. Fannal specializes in custom cover glass solutions. We can customize the dimensions, adjust glass thickness, add chemical strengthening, and apply AG (Anti-Glare), AR (Anti-Reflective), or AF (Anti-Fingerprint) surface coatings according to your device's environment.

Q4: How does the touch controller handle industrial interference such as thick work gloves or water droplets on the surface?

A4: The industrial-grade touch IC embedded in this 13.3" module can be custom-tuned by our engineers to support thick gloved touch (up to 5mm) and robust water-rejection filtering, preventing false triggers in harsh wet environments.

Q5: What is the long-term supply guarantee (lifecycle) for this 13.3-inch Full HD display module?

A5: Designed strictly for industrial and commercial projects, this 13.3-inch display module offers a stable lifecycle guarantee of 3 to 5 years. In case of critical component EOL (End of Life), Fannal ensures a seamless pin-to-pin compatible replacement option to prevent system redesigns.
