FN0620D002C
FANNAL
6.2
-30~80
-30~85
1024×600
ALL
RGB 24bit
1500
Customizable
| Quantity: | |
|---|---|
The 6.2-inch TFT display with 1024x600 resolution, RGB interface and 1500cd/m² luminance is an important component in automotive applications. It provides a high-quality visual interface for vehicles, integrating various functions and improving the intelligence and convenience of the driving experience. It not only meets the needs of drivers for vehicle information display but also enhances the overall value and competitiveness of the vehicle.
High-Brightness Backlight (1500 cd/m²)
Optimized LED backlight guarantees clear display visibility in daylight, vehicle cabins, or outdoor enclosures.
Sunlight-Readable Display
Maintains image clarity, color accuracy, and contrast under strong ambient illumination.
Compact Size & Embedded Integration
6.2" form factor with 1024×600 resolution — ideal for automotive, industrial, and portable embedded devices.
Reliable Performance in Harsh Conditions
Stable operation under temperature variation, vibration, and long-term usage.
Flexible Customization Options
Interface options, backlight tuning, protective cover glass, and optional optical bonding for specific OEM/ODM requirements.
LCD size(inch): | 6.2 (Diagonal) |
Resolution: | 1024(H)×600(V) |
Pixel Pitch: | 0.13425(H)x0.12872(V) |
Active Area(mm): | 137.472(H)×77.232(V) |
Module Size(mm): | 144.33(W)×88.16(H)×4.96(D) |
Display Mode(mm): | Normally Black, Transmissive |
Interface: | RGB 24bit |
View Direction: | ALL |
| Luminance(cd/m2): | 1500(Typ.) |
Operating Temperature(°C): | -30~+80 |
Storage Temperature(°C): | -30~+85 |
| Pin No. | Symbol | I/O | Description |
| 1-2 | LEDA | P | Power for LED backlight(Anode). |
| 3-4 | LEDK | P | Power for LED backlight(Cathode). |
| 5 | GND | P | Ground. |
| 6 | NC | - | No connection. |
| 7 | VDD | P | Power for Digital circuit. |
| 8 | NC | - | No connection. |
| 9 | DE | I | RGB data enable signal. |
| 10 | VSYNC | I | RGB frame synchronizing signal. |
| 11 | HSYNC | I | RGB line synchronizing signal. |
| 12 | B7 | I | Blue data bit 7. |
| 13 | B6 | I | Blue data bit 6. |
| 14 | B5 | I | Blue data bit 5. |
| 15 | B4 | I | Blue data bit 4. |
| 16 | B3 | I | Blue data bit 3. |
| 17 | B2 | I | Blue data bit 2. |
| 18 | B1 | I | Blue data bit 1. |
| 19 | B0 | I | Blue data bit 0. |
| 20 | G7 | I | Green data bit 7. |
| 21 | G6 | I | Green data bit 6. |
| 22 | G5 | I | Green data bit 5. |
| 23 | G4 | I | Green data bit 4. |
| 24 | G3 | I | Green data bit 3. |
| 25 | G2 | I | Green data bit 2. |
| 26 | G1 | I | Green data bit 1. |
| 27 | G0 | I | Green data bit 0. |
| 28 | R7 | I | Red data bit 7. |
| 29 | R6 | I | Red data bit 6. |
| 30 | R5 | I | Red data bit 5. |
| 31 | R4 | I | Red data bit 4. |
| 32 | R3 | I | Red data bit 3. |
| 33 | R2 | I | Red data bit 2. |
| 34 | R1 | I | Red data bit 1. |
| 35 | R0 | I | Red data bit 0. |
| 36 | GND | P | Ground. |
| 37 | DCLK | I | Clock for input data. |
| 38 | GND | I | Ground. |
| 39 | SHLR | I | Left/Right selection; H: Left to Right; L: Right to Left. |
| 40 | UPDN | I | Up/Down selection; H:Up to Down; L: Down to Up. |
| 41-43 | NC | - | No connection. |
| 44 | RESET | I | Global reset pin. |
| 45 | CS/NC | - | No connection. |
| 46 | SCL/NC | - | No connection. |
| 47 | SDI/NC | - | No connection. |
| 48 | GND | I | Ground. |
| 49-50 | NC | - | No connection. |
| Parameter | Symbol | Min. | Typ. | Max. | Unit |
| Analog Supply Voltage | VDD | 2.5 | 3.3 | 3.6 | V |
| Power Supply current | IDD | - | 80 | - | mA |
| Input logic high voltage | VIH | 0.7IOVCC | - | IOVCC | V |
| Input logic low voltage | VIL | 0 | - | 0.3IOVCC | V |
Why: the compact 6.2" size + 1024×600 resolution provides crisp text/graphics in a small footprint; 1500 cd/m² guarantees readability in bright sunlight or strong cabin glare.
Examples: secondary instrument cluster, parking-assist display, EV wall-mounted dashboard module.
Why: 1500 cd/m² is the primary enabler — maintains contrast/legibility in direct sunlight. The mid HD resolution (1024×600) is ideal for numeric readouts, graphs and simple UIs on portable devices.
Examples: handheld meters, environmental sensors, portable data loggers, field testers.
Why: compact form factor fits console cutouts; the high brightness + rugged mechanical stability handles open-cabin glare and variable lighting; if combined with vibration-tolerant mounting and appropriate temperature spec, it suits mobile equipment.
Examples: telematics displays, machine control panels on tractors/excavators, marine instrumentation.
Why: when displays are placed in semi-outdoor enclosures (awning, canopy, vehicle terminals), 1500 cd/m² preserves UI visibility; 1024×600 supports clear buttons, QR codes and simple graphics.
Examples: outdoor payment/readout terminals, EV charging station user panels, parking kiosks.
Why: industrial environments often have high ambient light or reflective surfaces; this module's brightness plus adequate contrast ensures operators can read alarms/metrics without shading the screen. The 6.2" size works for compact control modules.
Examples: PLC-mounted operator display, conveyor/local control panel, portable maintenance terminals.
Why: outdoor inverter / battery management UIs require high visibility under sun and clear numeric/graph plotting — the 1024×600 resolution with 1500 cd/m² meets these needs.
Examples: solar inverter local display, EV charger status panels, BMS handheld programmer.
Why: for compact POC devices that may be used near windows or in well-lit wards, the high brightness helps maintain contrast; the resolution supports patient data and simple imaging. (Note: medical use requires verifying disinfectant compatibility / certifications.)
Examples: portable vital-sign monitors, handheld diagnostic readers, bedside control panels.
Interface: confirm supported interface (LVDS/RGB/MCU) — matching host controller simplifies integration.
Optical bonding / cover glass: adding OCA/OCR or AR coating improves outdoor readability and ruggedness.
Thermal & vibration specs: ensure module operating temp / vibration tolerance align with vehicle or field usage.
Power & backlight control: consider PWM dimming or ambient dimming for night use in vehicles to avoid glare.
|
|
| |
|
|
|
|
|
|
|
|
To meet diverse integration needs, we offer extensive customisation for you, including:
• Size range: 1.77" to 15.6"
• Trusted panel partners: BOE, INNOLUX, JDI, Hannstar, CTC, TCL, and TIANMA.
• Panel types: IPS / TN / LTPS
• Operation Temperature: Industrial (-20 ~ 70°C), Automotive (-30 ~ 85°C)
• Tailored shape, length, and PIN definitions for full compatibility.
• EMI shielding and circuit optimisation.
• Supports multiple conversions: SPI, MCU, RGB, MIPI, LVDS, EDP
• Module material options: metal/plastic/metal–plastic integration
• High brightness up to 30,000 cd/m², ideal for outdoor or industrial use.
• Long lifetime up to 50,000 hours.
• Options: RGB / VGA / HDMI / LVDS / DVI / Type-C
• Fully compatible with custom TFT and LCD modules.
• Optimised design for stable image transmission and performance.
• Available Sizes: Up to 65"
• Structure Options: G+G, G+F+F, designed for industrial and automotive applications
• Touch Functions: Supports multi-touch, waterproof, glove touch, passive pen, gesture & palm rejection
• Operating Temperature:
Industrial Grade: –20°C ~ +70°C
Automotive Grade: –30°C ~ +85°
• Touch tuning and firmware optimization provided by FANNAL (in-house FW design)
• Trusted IC partners: EETI, ILITEK, GOODiX, FocalTech, Cypress, Microchip(FANNAL's Design Partner)
• High Reliability: Excellent anti-interference and long-term stability
• EMC Design: Full electromagnetic compatibility engineering to meet EMI/RFI and industrial standards
• Material Options:
Glass: 0.55mm–10.0mm
PMMA: 0.5mm–3.0mm
PC: 0.1mm–1.0mm
• Custom Design: CNC, Hot bending, 3D & 2.5D cover glass, ceramic printing, and PMMA integration
• Surface Treatments:
3A: AG / AR / AF
Anti-Microbial / Anti-Explosion
Optical Bonding | Size Range | Notes |
OCA | Up to 15.6” | Two fully automated production lines for high-volume manufacturing |
LOCA / OCR | Up to 32” | Excellent for high contrast and durability |
Silicone | Up to 32” | Ideal for rugged, large-size industrial applications |
FANNAL, founded in 2011, is a specialist in touch display solutions, delivering high-quality products and technical services worldwide. We design and manufacture in-house custom Displays, PCAP touch screens, and optical bonding. Our solutions serve industrial, outdoor, medical, automotive and other applications.
We are a fast-growing high-tech company financially backed by SECO, a European leader in electronic devices and embedded computing. We hold ISO 9001, ISO 14001, ISO 45001, ISO 13485, and IATF 16949 certifications. Our products are REACH and RoHS compliant, with test reports or declarations available upon request.
With stable quality and engineering support, FANNAL helps customers stay competitive and differentiate their products globally.
 | Well-Experienced: 15 years of experience in TFT Displays, AMOLED Displays, Touch Displays, Capacitive Tuchscreens, and Touch Monitors manufacturing. |
| One-Stop Solution: Full in-house process for touch screen, display, and optical bonding |
| Global Service: Italy, Germany, France, Spain, India, Japan, Singapore, and more — timely local support. |
| Strong Background: Financially backed by SECO, a top European leader in embedded and display solutions. |
| Reliable Supply: Our long-term supplier network ensures you receive consistent quality and reliable delivery, even in high-demand seasons. |
| Quality Assurance: ISO 9001, ISO 14001, ISO 45001, ISO 13485 & IATF 16949 certified; REACH & RoHS compliant. |
A: Yes, Fannal is a leading custom display & touchscreen manufacturer with 15 years of experience, offering full customization for LCD, TFT, AMOLED display panels, capacitive touchscreens, touch monitors, and optical bonding service.
Q: What makes this display high-brightness?
A: With a 1500 cd/m² LED backlight, it outperforms standard 250–400 cd/m² displays, maintaining clear visuals under sunlight or bright indoor light.
Q: Is it suitable for automotive dashboards?
A: Yes. Its high-brightness, compact 6.2″ form factor, and reliable TFT performance ensure excellent readability in vehicle cabins under varying light conditions.
Q: Can this display be used outdoors or in strong ambient light?
A: Absolutely. It is designed for sunlight-readable operation in outdoor instruments, portable field devices, and embedded systems.
Q: Are there customization options available?
A: Yes. Backlight tuning, interface options (LVDS, RGB, MCU), protective cover glass, and optical bonding are all available for OEM/ODM projects.
Q: How does high brightness help industrial applications?
A: Strong backlight and optimized optical design ensure the UI is visible in bright factory environments, improving efficiency and reducing errors.
