10.1 inch 1280x800 sunlight readable touch display module

10.1 inch Touch Display Module

Model:
FN101TPM
Cover OD (mm):
261.76*180.4*3.88
Operation Temp(℃):
-20~70
Storage Temp(℃):
-30~80
Display Interface:
LVDS
Resolution:
1280x800
Brightness(cd/m²):
500

Quantity:
Availability:





Inquiry Add to Basket

outdoor sunlight readable

Product Features

Product Drawing

Specification

Add Ons

Product Application

Introducing our 10.1-inch 1280x800 sunlight-readable touch display module, designed specifically for outdoor applications. This module features a high-resolution display that ensures clear visibility even in bright sunlight, making it ideal for various environments such as kiosks, outdoor signage, and industrial applications.

Key features include:

Sunlight Readability: Enhanced brightness and contrast for excellent visibility in direct sunlight.
Touch Functionality: Responsive touch technology for easy interaction, making it suitable for various applications.
Surface Treatment: The display has anti-glare (AG) and anti-fingerprint (AF) coatings, reducing reflections and smudges for a clearer view and improved usability.
Durability: Built to withstand outdoor conditions, ensuring reliable performance in various weather situations.
Versatile Connectivity: Compatible with various interfaces, facilitating integration into your existing systems.

This display module is perfect for any outdoor project requiring reliable performance and exceptional visibility!

屏幕截图 2024-10-28 173230

General Specifications：

Size(inch):	10.1
Module:	FN101TPM

TFT LCD
Resolution:	1280x800
Brightness（cd/m²）:	500
Display interface:	LVDS
Panel type:	IPS

Touch panel
Touch type:	capacitive touch
TP VA (mm):	217.36x136
Cover OD (mm):	261.76x180.4x3.88
TP Interface:	USB
Driver IC:	Microchip

Customization

COVER LENS:

Shape: cut in special shape, Printing: Silk printing/Ceramic printing, Material: PMMA/Glass, Thickness: 0.55mm~10.0mm, Surface treatment: AG, AR, AF, AB.

Sensor:

Sensor made by FANNAL,Narrow bezel design,Thickness selectable.

FPC:

Required shape available, Touch IC selectable, Interface selectable.

Bonding:

Air bonding/optical bonding, low reflection, All one black effect.

TFT Display:

In house manufacture/sunlight readable display/wide temperature display, IPS TFT display, Automotive grade display.

Add-on:

backlight board, AD board, wire sets.

Application

With the demand for custom projects going up every day, the bar type TFT market is growing correspondingly. And our bar type TFT solution can be perfectly used in many applications like industrial, automotive, medical, home appliance and maritime, etc.
