10.1 Inch Outdoor LCD Sunlight Readable And High Resolution 1920*1200

10.1-inch Outdoor TFT LCD Display

Model:
FN1010D045A
Size(inch):
10.1
Operation Temp(℃):
-20~80
Storage Temp(℃):
-30~85
Resolution:
1920×1200
Direction:
ALL
Interface:
LVDS
Brightness(cd/m²):
1000
Touch Screen:
Customizable

Quantity:
Availability:





Inquiry Add to Basket Download

Outdoor LCD

Drawing

Specification

Product Application

Customization

FAQ

Drawing

FN1010D045A

Specification

General Specifications：

LCD size(inch):	10.1 (Diagonal)
Resolution:	1920(H)×1200(V)
Pixel Pitch:	0.1134(H)x0.1134(V)
Active Area(mm):	217.728(H)×136.08(V)
Module Size(mm):	229.46(W)x149.1(H) ×4.8(D)
Display Mode(mm):	Normally Black, Transmissive
Interface:	LVDS
View Direction:	ALL
Luminance(cd/m2):	1000(Typ.)
Operating Temperature(°C):	-20~+80
Storage Temperature(°C):	-30~+85

Interface:

Pin No.	Symbol	I/O	Description
1-2	LEDK	P	Power for LED backlight(Cathode).
3-4	LEDA	P	Power for LED backlight(Anode).
5	NC	-	No connection.
6	GND	P	Ground.
7	ERXIN3P	I	LVDS Positive differential data signal.(Even data)
8	ERXIN3N	I	LVDS Negative differential data signal.(Even data)
9	GND	P	Ground.
10	ERXIN2P	I	LVDS Positive differential data signal.(Even data)
11	ERXIN2N	I	LVDS Negative differential data signal.(Even data)
12	GND	P	Ground.
13	ERXCLKP	I	LVDS Positive differential clock signal.(Even clock)
14	ERXCLKN	I	LVDS Negative differential clock signal.(Even clock)
15	GND	P	Ground.
16	ERXIN1P	I	LVDS Positive differential data signal.(Even data)
17	ERXIN1N	1	LVDS Negative differential data signal.(Even data)
18	GND	P	Ground.
19	ERXIN0P	I	LVDS positive differential data signal.(Even data)
20	ERXIN0N	I	LVDS Negative differential data signal.(Even data)
21	NC	I	Ground.
22	ORXIN3P	I	LVDS Positive differential data signal.(Odd data)
23	ORXIN3N	I	LVDS Negative differential data signal.(Odd data)
24	GND	P	Ground.
25	ORXIN2P	I	LVDS Positive differential data signal.(Odd data)
26	ORXIN2N	I	LVDS Negative differential data signal.(Odd data)
27	GND	P	Ground.
28	ORXCLKP	I	LVDS Positive differential data signal.(Odd data)
29	ORXCLKN	I	LVDS Negative differential data signal.(Odd data)
30	GND	P	Ground.
31	ORXIN1P	I	LVDS Negative differential data signal.(Odd data)
32	ORXIN1N	I	LVDS Positive differential data signal.(Odd data)
33	GND	P	Ground.
34	ORXIN0P	I	LVDS Positive differential data signal.(Odd data)
35	ORXIN0N	I	LVDS Negative differential data signal.(Odd data)
36	GND	P	Ground.
37	IIC_SDA	I	OTP_SDA.
38	IIC_SCL	I	OTP_SCL.
39	VDD_OTP	P	OTP Power supply VDD OTP=8.6V
40	EEPN	-	No connection.
41-45	VDDIN	P	Power supply:+3.3V

Electrical Characteristics:

Parameter	Symbol:	Min.	Typ.	Max.	Unit
Forward Voltage	VF	27.0	30.5	34.0	V
Forward Current	IF	-	240	-	mA

Application

This 10.1 inch outdoor LCD is engineered for environments where visibility under strong ambient light is critical. The combination of high brightness (1000 cd/m²), IPS wide viewing, and industrial-grade reliability makes it effective in both outdoor and demanding indoor applications.

1. Outdoor Kiosks & Self-Service Terminals

The high brightness ensures that user interfaces, menus, QR codes and instructions remain readable even in strong daylight.
→ Suitable for ticketing machines, outdoor payment stations, information kiosks and wayfinding displays.

2. Automotive & Transportation Displays

With wide temperature tolerance and daylight-readable performance, the outdoor LCD works reliably where displays are exposed to shifting light levels — such as in vehicle cabins or transportation hubs.
→ Examples: automotive dashboards, public transit info screens, depot management panels.

3. Industrial Field Equipment

For industrial outdoor environments (e.g., factories, construction, inspection systems) this outdoor LCD panel offers clear UI and data visibility under bright environmental light.
→ Examples: field controllers, inspection terminals, machine interfaces mounted near windows or outdoor lines.

4. Outdoor Digital Signage & Advertising

The high brightness improves the visibility of visual content and messaging, keeping signage legible under daylight conditions where standard LCDs would wash out.
→ Examples: digital advertising boards, outdoor promotional displays, campus signage.

5. Semi-Outdoor & Outdoor Infotainment

For semi-exposed environments where touchscreens may be used outdoors but protected from direct rain, this outdoor LCD panel ensures good readability with strong contrast.
→ Examples: EV charging stations, ride-share terminals, outdoor kiosks with canopies.

Industrial Panels

Medical Equipment

Fitness Equipment

Engineering Plant

Motorbike

Vending Machine

Home Application

Customization

To meet diverse integration needs, we offer extensive customisation for you, including:

● Custom Display Options

LCD Panel

• Size range: 1.77" to 15.6"
• Trusted panel partners: BOE, INNOLUX, JDI, Hannstar, CTC, TCL, and TIANMA.
• Panel types: IPS / TN / LTPS
• Operation Temperature: Industrial (-20 ~ 70°C), Automotive (-30 ~ 85°C)

Interface Design

• Tailored shape, length, and PIN definitions for full compatibility.
• EMI shielding and circuit optimisation.
• Supports multiple conversions: SPI, MCU, RGB, MIPI, LVDS, EDP

Back Light

• Module material options: metal/plastic/metal–plastic integration
• High brightness up to 30,000 cd/m², ideal for outdoor or industrial use.
• Long lifetime up to 50,000 hours.

Driver Board

• Options: RGB / VGA / HDMI / LVDS / DVI / Type-C
• Fully compatible with custom TFT and LCD modules.

• Optimised design for stable image transmission and performance.

Custom Touchscreen

● Custom Touchscreen Options

Touch Sensor

• Available Sizes: Up to 65"

• Structure Options: G+G, G+F+F, designed for industrial and automotive applications

• Touch Functions: Supports multi-touch, waterproof, glove touch, passive pen, gesture & palm rejection

• Operating Temperature:

Industrial Grade: –20°C ~ +70°C

Automotive Grade: –30°C ~ +85°

Touch Controller (IC)

• Touch tuning and firmware optimization provided by FANNAL (in-house FW design)
• Trusted IC partners: EETI, ILITEK, GOODiX, FocalTech, Cypress, Microchip(FANNAL's Design Partner)
• High Reliability: Excellent anti-interference and long-term stability
• EMC Design: Full electromagnetic compatibility engineering to meet EMI/RFI and industrial standards

Cover Lens

• Material Options:

Glass: 0.55mm–10.0mm
PMMA: 0.5mm–3.0mm
PC: 0.1mm–1.0mm
• Custom Design: CNC, Hot bending, 3D & 2.5D cover glass, ceramic printing, and PMMA integration
• Surface Treatments:
3A: AG / AR / AF
Anti-Microbial / Anti-Explosion

● Custom Optical Bonding Service

Optical Bonding	Size Range	Notes
OCA	Up to 15.6”	Two fully automated production lines for high-volume manufacturing
LOCA / OCR	Up to 32”	Excellent for high contrast and durability
Silicone	Up to 32”	Ideal for rugged, large-size industrial applications

FAQ

1. Is 1000 cd/m² sufficient for direct sunlight readability?

1000 cd/m² significantly improves visibility compared to standard 300–500 cd/m² panels. For full direct sunlight exposure, optical bonding and anti-reflective surface treatment are recommended to further enhance contrast and reduce internal reflections.

2. What interface does this 10.1″ outdoor LCD use?

The panel uses an LVDS interface for stable signal transmission in embedded and industrial systems. HDMI compatibility requires an external driver board.

3. What operating temperature range does the panel support?

The panel supports an operating range of –20 °C to +80 °C and storage from –30 °C to +85 °C. Thermal design and backlight driving conditions should be considered in high-temperature environments to ensure longevity.

4. Can touch functionality be integrated?

Yes. Projected capacitive or resistive touch panels can be integrated based on application requirements, including optical bonding and front-panel sealing for outdoor use.

5. Is this panel suitable for long-term industrial deployment?

Yes. The IPS structure, LVDS interface, and high-brightness backlight make it suitable for industrial systems operating in bright or semi-outdoor environments. Lifecycle confirmation is recommended for long-term projects.
