11.6 Inch TFT Display High Resolution 1920*1080 IPS LCD

Name: 11.6 Inch TFT Display High Resolution 1920*1080 IPS LCD
Brand: FANNAL
Rating: 5.0 (82 reviews)

11.6-inch IPS TFT LCD Displays

Model:
FN1160D001A
Brand:
FANNAL
Size(inch):
11.6
Display AA(mm):
256.32*144.18
Operation Temp(℃):
-20~70
Storage Temp(℃):
-30~80
Resolution:
1920x1080
Direction:
ALL
Interface:
eDP
Brightness(cd/m²):
500
Touch Screen:
Customizable

Quantity:
Availability:





Inquiry Add to Basket Download

11.6 inch TFT display tft display screen buy display screen

Product Features

Drawing & Specifications

Customization

Product Application

FAQ

详情页IPS工控

This 11.6-inch display delivers a crisp Full HD (1920x1080) visual experience in a compact, industrial-grade form factor. Utilizing a Normally Black IPS-like display mode, it offers consistent, vibrant colors and 16.7M display colors with an all-around (ALL) viewing angle.

Designed for versatility and reliability, this module features a slim 6.1mm profile and weighs only 250g, making it the perfect choice for portable industrial devices, medical monitors, and sleek human-machine interfaces (HMI). With an operating temperature range of -20°C to +70°C, it ensures stable performance in varied professional environments.

Key Features

Crisp Full HD Resolution: The 1920x1080 (1080p) resolution and 0.1335mm pixel pitch provide high-density detail, essential for complex technical data and high-definition imaging.
Ultra-Lightweight & Slim Design: Weighing just 250g with a thickness of 6.1mm, this module allows for high portability and easy integration into space-constrained housings.
Full Viewing Angle (IPS Technology): Consistent image quality and color accuracy from any perspective, ensuring visibility for multiple operators or dynamic viewing positions.
Industrial-Grade Reliability: Engineered to operate reliably between -20°C and +70°C, handling the thermal demands of industrial machinery and professional enclosures.
Professional Color Depth: Supports 16.7 million colors (8-bit) with an RGB vertical stripe arrangement, delivering smooth gradients and professional-grade color reproduction.
Reliable LVDS Interface: Uses a standard LVDS interface for high-speed data transmission, minimizing electromagnetic interference (EMI) and ensuring compatibility with mainstream industrial controllers.

Drawing

屏幕截图 2024-09-29 155310

Specifications

General Specifications：

LCD size(inch):	11.6 (Diagonal)
Resolution:	1920(H)×1080(V)
Pixel Pitch:	0.1335(H)x0.1335(V)
Active Area(mm):	256.32(H)×144.18(V)
Module Size(mm):	264.72(W)x164.42(H) ×6.1(D)
Display Mode(mm):	Normally Black, Transmissive
Interface:	LVDS
Pixel arrangement:	RGB-Vertical Stripe
View Direction:	ALL
Display Colors	16.7M
Weight(g):	250(Typ.)
Luminance(cd/m2):	500(Typ.)
Operating Temperature(°C):	-20~+70
Storage Temperature(°C):	-30~+80

Interface:

Pin No.	Symbol	I/O	Description
1	CABC-EN	I	CABC-EN.
2	GND	P	Ground.
3	LANE1-N	I	eDP RX channel 1 negative.
4	LANE1-P	I	eDP RX channel 1 positive.
5	GND	P	Ground.
6	LANE0-N	I	eDP RX channel 0 negative.
7	LANE0-P	I	eDP RX channel 0 positive.
8	GND	P	Ground.
9	AUX-CH-P	I	eDP AUX CH negative.
10	AUX-CH-N	I	eDP AUX CH positive.
11	GND	P	Ground.
12-13	LDC-VCC	I	3.3V
14	LCD-TEST	I	Panel self test enable.
15-16	GND	P	Ground.
17	HPD	I	Hot plug detect output.
18-23	NC	-	No connection.
24	MSCL	-	For debug.
25	MSDA	-	For debug.
26-30	NC	-	No Connection.

Electrical Characteristics:

Parameter	Symbol:	Min.	Typ.	Max.	Unit
Forward Current Voltage	VF	27.0	30.0	34.0	V
Forward Current	IF	-	240	-	mA

Customizations

To meet diverse integration needs, we offer extensive customisation for you, including:

● Custom Display Options

LCD Panel

• Size range: 1.77" to 15.6"
• Trusted panel partners: BOE, INNOLUX, JDI, Hannstar, CTC, TCL, and TIANMA.
• Panel types: IPS / TN / LTPS
• Operation Temperature: Industrial (-20 ~ 70°C), Automotive (-30 ~ 85°C)

Interface Design

• Tailored shape, length, and PIN definitions for full compatibility.
• EMI shielding and circuit optimisation.
• Supports multiple conversions: SPI, MCU, RGB, MIPI, LVDS, EDP

Back Light

• Module material options: metal/plastic/metal–plastic integration
• High brightness up to 30,000 cd/m², ideal for outdoor or industrial use.
• Long lifetime up to 50,000 hours.

Driver Board

• Options: RGB / VGA / HDMI / LVDS / DVI / Type-C
• Fully compatible with custom TFT and LCD modules.

• Optimised design for stable image transmission and performance.

Custom Touchscreen

● Custom Touchscreen Options

Touch Sensor

• Available Sizes: Up to 65"

• Structure Options: G+G, G+F+F, designed for industrial and automotive applications

• Touch Functions: Supports multi-touch, waterproof, glove touch, passive pen, gesture & palm rejection

• Operating Temperature:

Industrial Grade: –20°C ~ +70°C

Automotive Grade: –30°C ~ +85°

Touch Controller (IC)

• Touch tuning and firmware optimization provided by FANNAL (in-house FW design)
• Trusted IC partners: EETI, ILITEK, GOODiX, FocalTech, Cypress, Microchip(FANNAL's Design Partner)
• High Reliability: Excellent anti-interference and long-term stability
• EMC Design: Full electromagnetic compatibility engineering to meet EMI/RFI and industrial standards

Cover Lens

• Material Options:

Glass: 0.55mm–10.0mm
PMMA: 0.5mm–3.0mm
PC: 0.1mm–1.0mm
• Custom Design: CNC, Hot bending, 3D & 2.5D cover glass, ceramic printing, and PMMA integration
• Surface Treatments:
3A: AG / AR / AF
Anti-Microbial / Anti-Explosion

● Custom Optical Bonding Service

Optical Bonding	Size Range	Notes
OCA	Up to 15.6”	Two fully automated production lines for high-volume manufacturing
LOCA / OCR	Up to 32”	Excellent for high contrast and durability
Silicone	Up to 32”	Ideal for rugged, large-size industrial applications

Technical Applications

Medical Technology: Portable ultrasound machines, patient monitors, and diagnostic tablets.
Industrial Automation: High-end HMI panels and rugged field-testing equipment.
Transportation: Specialized vehicle consoles and aircraft cabin displays.
Commercial Terminals: Premium Point-of-Sale (POS) systems and high-end security monitors.

Automotive Display

Kiosk touch screen

Railway display

E-bike display

Outdoor display

Industrial display

Medical touch screen

Gym-screen

Engineering Plant

Motorcycle display

Vending Machine Display

Embedded display

FAQ

Q1: What are the main advantages of an 11.6-inch display with 1920x1080 resolution?

Answer: The Full HD (1080p) resolution provides high pixel density (0.1335mm pitch), delivering exceptionally sharp text and detailed graphics. This is critical for medical imaging, complex industrial HMI, and professional monitoring equipment.

Q2: Is this 11.6" LCD suitable for portable or handheld devices?

Answer: Yes, it is specifically designed for portability. Weighing only 250g and measuring 6.1mm in thickness, it allows engineers to create slim, lightweight handheld terminals without compromising on screen durability or performance.

Q3: Can this display operate in environments with extreme temperatures?

Answer: This module supports a wide operating temperature range from -20°C to +70°C. It is built to maintain stable visual performance in unheated industrial warehouses or near high-heat machinery.

Q4: Does the LVDS interface support long-distance signal transmission?

Answer: LVDS is highly effective for reducing electromagnetic interference (EMI). It provides a stable, high-speed data connection between the controller board and the 1080p panel, even in electronically noisy industrial environments.

Q5: Are there custom touch screen options available for this 11.6-inch panel?

Answer: Yes, we provide full customization for Projected Capacitive (PCAP) touch sensors. We can add custom cover glass thickness, anti-glare (AG) coatings, or optical bonding to enhance outdoor readability and impact resistance.
